Allegro 8" Axial AC Plastic Blower with 15' Ducting

Mfr.: Allegro Industries
Item #: I094580
Mfr. #: 9533-15
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $574.88
i h h

Description

A high-output compact axial blower designed for easy use and storage without sacrificing airflow. Available as a complete unit with 15' (4.75 m) of ducting and storage canister, certified to CSA Standard C22.2 No.113.
  • Compact canister is lightest and smallest in industry
  • High output from compact axial blower

Features

  • 8 inch (20.3 cm) axial AC plastic blower
  • Available with or without canister & ducting
  • Compact canister in 9533-15 model is lightest and smallest in industry
  • Polyethylene housing and canister assembly
  • Lightweight, corrosion-, UV- and chemical-resistant
  • Super quiet, in 'safety orange' color
  • Bottom enclosure to protect electrical components
  • Carry handle molded into blower and canister housing
  • Steel powder coated grill
  • 1/3 HP motor
  • UL Recognized, CSA Certified, CE Certified
  • 115V-230V AC, 50/60 Hz, Single Phase
  • 2800/3400 RPM
  • On/Off rocker switch
  • 4.8A-2.4A (50 Hz) / 4.5A-2.2A (60 Hz) amps
  • 10' (3.05 m) AWG cord
  • NEMA 5-15P plug
  • Polypropylene nine blade fan
  • Retractable, non-collapsible ducting design
  • Single ply, PVC coated vinyl and polyester materials
  • Temperature resistant up to 180F (82.2C)
  • Yellow color with black weather strip
  • Integrated nylon attachment strap
  • Class 1 hard drawn spring steel wire helix
  • Meets ASTM 227 specs

Includes

  • 15' (4.75 m) ducting
  • Storage canister

Specifications

Length26 inch (66.0 cm)
Width13.5 inch (34.2 cm)
Height14.5 inch (36.8 cm)
Weight25 lbs (11.3 kg)
Ducting Length15 (4.75 m)
Motor HP1/3 HP
Voltage115V-230V AC
Frequency50/60 Hz
PhaseSingle Phase
RPM2800/3400
Amps 50Hz4.8A-2.4A
Amps 60Hz4.5A-2.2A
Cord Length10 (3.05 m)
Plug TypeNEMA 5-15P
Fan MaterialPolypropylene
Fan Blades9
Ducting MaterialPVC vinyl/polyester
Max Temp180 degF (82.2 degC)
Ducting ColorYellow
Wire Helix ClassClass 1
Housing MaterialPolyethylene
ColorSafety orange
CertificationsUL, CSA, CE
CSA StandardC22.2 No.113
Free Air CFM831 CFM
One Bend CFM709 CFM
Two Bends CFM586 CFM
Products specifications
Country of Origin Varies (subject to change)
Hose Inner Diameter 8 in
Hose Length 15 ft
Power Source Corded Electric
Type Axial AC Plastic Blower
*
*
*
