Greenstreak Model 735 PVC Waterstop 9"x3/8" RCB, 50 ft roll, priced per foot

Mfr.: Greenstreak -Sika
Item #: I101485
Mfr. #: 419524
*
Pickup at San Diego | Change Delivering to 92111 | Change

Digital Downloads
Price: $18.67
i h h

Description

Greenstreak Model 735 is a 9 in. flexible PVC ribbed waterstop with a center bulb for moving expansion joints in large concrete structures. The wide profile and hollow center bulb accommodate substantial joint movement and high hydrostatic head, while the ribbed legs anchor the strip into the concrete to form a watertight diaphragm. Approved for potable water contact per NSF/ANSI 61.
  • Flat ribbed profile enhances mechanical bond within poured concrete
  • Optimized for construction joint water sealing
  • Durable PVC material provides resistance to water, chemicals, and aging
  • Used in slabs, walls, and structures requiring dependable watertight joints
  • Flexible PVC with ribbed center bulb for expansion/moving joints
  • Wide 9 in. profile for high hydrostatic head and large joints
  • Hollow center bulb absorbs joint movement
  • NSF/ANSI 61 certified for potable water contact
  • Complies with U.S. Army Corps of Engineers spec CRD-C 572-74

Features

  • Flat ribbed profile enhances mechanical bond within poured concrete
  • Optimized for construction joint water sealing
  • Durable PVC material provides resistance to water, chemicals, and aging
  • Used in slabs, walls, and structures requiring dependable watertight joints
  • Flexible PVC with ribbed center bulb for expansion/moving joints
  • Wide 9 in. profile for high hydrostatic head and large joints
  • Hollow center bulb absorbs joint movement
  • NSF/ANSI 61 certified for potable water contact
  • Complies with U.S. Army Corps of Engineers spec CRD-C 572-74
  • Model: 735
  • Size: 9 in. x 3/8 in.
  • Profile: Ribbed Center Bulb (RCB)
  • Roll length: 50 ft
  • Material: PVC
  • Joint type: Moving / expansion joint
  • Priced per foot

Specifications


Model735Size9 inch x 3/8 inch
ProfileRibbed Center Bulb (RCB)Roll length50 ft
MaterialPVCJoint typeMoving / expansion joint
Shore A Hardness79 +/- 3 (ASTM D2240)Tensile Strength2000 psi min (ASTM D638)
StandardsNSF/ANSI 61; CRD-C 572-74PricingPer foot
*
*
*
