WR Meadows Total Drain 150B - 2' x 50' Roll

Mfr.: WR Meadows
Item #: I055660
Mfr. #: 5754250
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $344.28
i h h

Description

MEL-DRAIN TOTAL-DRAIN is a prefabricated drainage system combining a standard sheet drain with a built-in high-flow section for efficient water collection and horizontal discharge. It includes a non-woven filter fabric to prevent soil intrusion while allowing water flow.
  • Two-part design with 12 inch of 7/16 inch core for collection and 12 inch of 1 inch core for high flow
  • Flow capacity: sheet drain 21 gpm/ft, high profile 100 gpm @ HG=1.0
  • Compressive strength: 9,000 lb/sf
  • Roll dimensions: 2 ft wide x 50 ft long, weight 30 lb

Features

  • Prefabricated geocomposite drain with HIPS core and polypropylene filter fabric
  • Eliminates need for perforated pipe and select backfill
  • Fast and easy installation with standard connectors and corner guards
  • Provides full-coverage protection to waterproofing materials

Specifications


Core MaterialHIPSFilter FabricNon-woven needle-punched polypropylene
Sheet Drain Flow Capacity21 gpm/ft @ HG=0.1High Profile Flow Capacity100 gpm @ HG=1.0
Compressive Strength9,000 lb/sfRoll Length50 ft
Roll Width2 ftRoll Weight30 lb
*
*
*
